DYNAMAX DP600 490W Power Amplifier
Enquiry Now
DYNAMAX DP600 490W Power Amplifier
Available:
In Stock
- Product SKU: SRAMDX-DP600
- Category: Commercial, DYNAMAX, Power Amplifiers, Pro-Audio Systems
RM1,399.00
Enquiry Now
Share:
OVERVIEW
DP600 hankered higher speed, bigger damping factor, more rich content and advanced protection system. Designed with excellent cooling system, compact and stable mechanical aseismatic capabilities, SMT technology as well as precise components. It is able to load for stereo 2 ohm, bridge 4 ohm, and adapts to drive line array speaker system.
APPLICATION
- Live concert
- Disco
- Night clubs
FEATURES
- Higher speed, bigger damping factor, more rich functions
- Advanced protection system
- Designed with excellent cooling system, compact
- Stable mechanical aseismatic capabilities
- SMT technology with precise components
- Able to load for stereo 2 ohm, bridge 4 ohm
- Adapts to drive line array speaker system
SPECIFICATION
- Output Power (RMS) :
- 8 Ω Stereo - 490W
- 4 Ω Stereo - 760W
- Bridged Mode (RMS) :
- 8 Ω Bridge Mono - 1540W
- Frequency Response :
- 20Hz - 20kHz +1/-1dB
- THD + N (20Hz - 20kHz) for 1 W THD + N : 0.1
- Damping Factor : 300
- Signal to Noise Ratio : ≥100 dB
- Input Sensitivity : 0.775V / 1.0V / 1.4V
- Input Impedance : >10K Ω & balance or unbalanced & all models
- Front Panel Controls :
- AC Power Switch
- Protect (Red)
- Clip (Orange)
- Signal (Green)
- Power (Green)
- Gain Controls Input Mode Switch : Bridge (Red)
- Rear Panel Controls :
- Parallel (Yellow)
- Stereo (Green)
- Sensitivity : 0.775V (Red), 1.0V (Yellow), 1.4V (Green)
- Limiter : OFF (Red), ON (Green)
- Grounding : Lift (Red), Ground (Green)
- Connectors (Inputs) :
- XLR Male, XLR Female : RCA
- Connectors (Outputs) :
- Binding Posts, Output Red, Common Black
- Speakon Dual CH 1+/ 1-, Bridge Mono
- CH1+ / 2+
- Cooling : Variable speed fans & front to rear air flow
- Output Circuit : Class H
- Power Requirements : 220V / 50-60Hz
- Product Dimension : 483 x 89 x 396 mm
- Net Weight : 17 kg
- Gross Weight : 19 kg
