Studiomaster SRQ62 2 X 31 band 2U Graphic Equalizer

Available: Out of Stock
RM1,100.00
Enquiry Now
Share:

Features

  • 2 x 31 band 1 / 3 octave graphic equaliser
  • Input trim and signal / clip led indication
  • Switchable cut / boost range and 40Hz high pass filter
  • Bypass switch for quick comparison
  • 19″ 2U

Specification

  • Centre frequencies:  SRQ62 (20Hz-20kHz)
  • Frequency response: 10Hz – 55kHz
  • Frequency cut/boost: 12dB
  • Distortion: 0.004%
  • Signal to noise ratio: 98dB
  • Gain cut/boost: selectable 15dB / 6dB
  • Input trim range: infinity to +6dB
  • Maximum input level: +23dBu balnced, +20dBu unbalanced
  • Maximum output level: +23dBu balnced, +20dBu unbalanced
  • Input impedance: 20k ohms balanced, 10k ohms unbalanced
  • Output impedance: <150 ohms
  • Hi pass filter: SRQ62 (40Hz @ 12dB/oct), SRQ62L (12-285Hz @12dB/oct)
  • Metering: 2x M10 hanging points
  • Meter calibration: 2x M10 hanging points
  • Connections: 2x M10 hanging points
  • Fader travel: 2x M10 hanging points
  • Power requirements: 2x M10 hanging points
  • Power consumption: 2x M10 hanging points
  • Dimension W*D*H: 483×186 x 88mm
  • Weight: 3.5kg
