Fonestar PROX-240S 240W PA Amplifier, Public Address Amplifier

Available: In Stock
RM4,450.00
Enquiry Now
Share:
  • Power: 240 W RMS
  • Response: 40-20,000 Hz (-10 dB)
  • Distortion: THD+N: < 1% @ 1 kHz
  • S/N Ratio: >77 dB
  • Protections: Overcurrent, DC and short-circuit at the output
  • Inputs: CH 1 balanced mic/line with 48V Phantom, Combo connector (XLR + 6.3mm) and euroblock
  • CH 2 and 3 mic/line balanced with 48V Phantom. Euroblock connector
  • Mic signal level: 6 mV RMS (-44 dBV) / 600 Ω
  • Line signal level: 250 mV RMS (-12 dBV) / 100k Ω
  • 2 AUX. 2 x RCA and euroblock connector. Signal level 300 mV RMS (-10 dBV) / 47,000 Ω
  • 1 emergency. Euroblock connector. Signal level loudspeaker line 100 V
  • 1 Mute (Emergency Priority) by contact closure. Euroblock connector
  • Outputs: line. 2 x RCA connector. 1.25 V RMS (+2 dBV) signal level, 100 V or 4 Ω speaker output. Connector screw terminals
  • Impedance: 4 Ω and 100 V line (83 Ω)
  • Functions: Input priority (Voice over VOX inputs): 100V Emergency input with highest priority, attenuates all other inputs.
  • Mute by contact closure, attenuates all inputs except the 100V Emergency input.
  • Channel 1 with priority over all other inputs, level selectable.
  • Channel 2 and 3 with priority over auxiliary inputs, level selectable.
  • Other functions: Power on, protection, signal peak and output signal indicators.
  • Temperature-controlled cooling by forced ventilation
  • Controls: Microphone volume, Mic/line/phantom selector, Master volume, Aux input selector, Tone: bass and treble (+/- 10 dB 100 Hz and 10k Hz), Microphone gain, Priority activation signal level (VOX)
  • Power Supply: 230/115 V AC 50-60 Hz, 320 W, Fuse AC 230 V 3.15 A / 115 V 6 A
  • Dimensions: 433 x 89 x 360 mm depth. 2 U 19” rack
  • Weight: 11.3 kg
  • Accessories: Power cable, Rack mounts
